Debugging Logic

💡 TL;DR - Debugging Logic

Debug rules using system-generated logging and your IDE debugger.



Using the debugger

Use the debugger as shown below. Note you can stop in lambda functions.

  • Key point: rows are instances of your Data Model classes (database/models.py). These classes define the attributes and relationships; this information powers IDE code completion, the debugger, etc.

    • Recall the Data Model classes were built by API Logic Server, by introspecing the database

Logic Debugger



Logic Log

Logging is performed using standard Python logging, with a logger named logic_logger. Use info for tracing, and debug for additional information (e.g., all declared rules are logged).

In addition, the system logs all rules that fire, to aid in debugging. Referring the the screen shot above:

  • Each line represents a rule execution, showing row state (old/new values), and the {reason} that caused the update (e.g., client, sum adjustment)
  • Log indention shows multi-table chaining
